Drop two pebbles into water and the ripples overlap. Where two crests meet, they reinforce each other; where a crest meets an equally strong trough, they cancel. In this SwingLoops example, we use two sinusoidal waves to recreate that pattern pixel by pixel.

The result is a portrait animation with cyan crests, pink troughs, and dark bands where the combined displacement is small. The example uses Java Swing and Java 2D without external libraries.

Source code

Save the following code as RippleInterference.java:

import java.awt.Color;
import java.awt.Dimension;
import java.awt.Graphics;
import java.awt.Graphics2D;
import java.awt.RenderingHints;
import java.awt.image.BufferedImage;
import java.awt.image.DataBufferInt;
import javax.swing.JFrame;
import javax.swing.JPanel;
import javax.swing.SwingUtilities;
import javax.swing.Timer;

public class RippleInterference extends JPanel {
    private static final int W = 180, H = 320;
    private static final int AX = 52, BX = 128, SY = 160;
    private static final double TAU = 2 * Math.PI;
    private static final double CYCLE = 8.0;
    private static final Color BACKGROUND = new Color(6, 12, 26);

    private final BufferedImage image =
            new BufferedImage(W, H, BufferedImage.TYPE_INT_RGB);
    private final int[] pixels =
            ((DataBufferInt) image.getRaster().getDataBuffer()).getData();
    private final float[] sine = new float[W * H];
    private final float[] cosine = new float[W * H];
    private final Timer timer = new Timer(33, _ -> repaint());
    private long start;

    public RippleInterference() {
        setPreferredSize(new Dimension(450, 800));
        setBackground(BACKGROUND);
        for (int y = 0; y < H; y++) {
            for (int x = 0; x < W; x++) {
                int i = y * W + x;
                double a = Math.hypot(x - AX, y - SY);
                double b = Math.hypot(x - BX, y - SY);
                double ka = TAU * a / 21, kb = TAU * b / 21;
                double wa = 1 / (1 + a / 110);
                double wb = 1 / (1 + b / 110);
                sine[i] = (float) (wa * Math.sin(ka) + wb * Math.sin(kb));
                cosine[i] = (float) (wa * Math.cos(ka) + wb * Math.cos(kb));
            }
        }
    }

    @Override
    public void addNotify() {
        super.addNotify();
        start = System.nanoTime();
        timer.start();
    }

    @Override
    public void removeNotify() {
        timer.stop();
        super.removeNotify();
    }

    private void render(double seconds) {
        double phase = TAU * 5 * ((seconds % CYCLE) / CYCLE);
        double c = Math.cos(phase), s = Math.sin(phase);
        for (int i = 0; i < pixels.length; i++) {
            // sin(k*d - phase), summed across both sources.
            double wave = sine[i] * c - cosine[i] * s;
            double glow = Math.min(1, Math.abs(wave) / 1.5);
            glow *= glow;
            int r = 6 + (int) (glow * (wave >= 0 ? 32 : 238));
            int g = 12 + (int) (glow * (wave >= 0 ? 222 : 98));
            int b = 26 + (int) (glow * (wave >= 0 ? 229 : 143));
            pixels[i] = (r << 16) | (g << 8) | b;
        }
    }

    @Override
    protected void paintComponent(Graphics graphics) {
        super.paintComponent(graphics);
        drawFrame(graphics, getWidth(), getHeight(),
                  (System.nanoTime() - start) / 1e9);
    }

    void drawFrame(Graphics graphics, int width, int height, double seconds) {
        render(seconds);

        Graphics2D g = (Graphics2D) graphics.create();
        try {
            double scale = Math.min(width / (double) W,
                                    height / (double) H);
            g.translate((width - W * scale) / 2,
                        (height - H * scale) / 2);
            g.scale(scale, scale);
            g.setRenderingHint(RenderingHints.KEY_INTERPOLATION,
                               RenderingHints.VALUE_INTERPOLATION_BILINEAR);
            g.drawImage(image, 0, 0, null);
            g.setColor(new Color(237, 249, 255));
            g.fillOval(AX - 2, SY - 2, 4, 4);
            g.fillOval(BX - 2, SY - 2, 4, 4);
        } finally {
            g.dispose();
        }
    }

    static void main() {
        SwingUtilities.invokeLater(() -> {
            JFrame frame = new JFrame("SwingLoops - Ripple Interference");
            frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
            frame.setContentPane(new RippleInterference());
            frame.pack();
            frame.setLocationRelativeTo(null);
            frame.setVisible(true);
        });
    }
}

Run the example

From the directory containing the source file, run:

javac RippleInterference.java
java RippleInterference

The default window is 450 × 800 pixels. Resize it to see the pattern scale while keeping its aspect ratio. Close the window to exit.

Calculate a ripple at each pixel

A circular wave depends on how far the pixel is from its source. The program finds that distance with Math.hypot():

double a = Math.hypot(x - AX, y - SY);
double ka = TAU * a / 21;
double wa = 1 / (1 + a / 110);

Here, TAU is one full turn in radians, or 2π. Dividing by 21 means the spatial phase advances by one turn every 21 image pixels. The factor wa makes the amplitude smaller as distance increases.

A source contributes wa × sin(ka − phase). As the shared time phase increases, points of equal phase move outward from the source. The program adds this contribution to the corresponding contribution from the second source.

The waves have the same frequency and start in phase. If the difference between the two distances is a whole wavelength, their oscillations reinforce each other. At half a wavelength, one oscillation opposes the other. Their amplitudes may differ because of the distance weights, so those opposing waves can leave a small residual instead of canceling completely.

Cache the parts that depend on position

Calculating each distance and calling sine twice for every pixel on every repaint would repeat work. The sources stay fixed, so the code uses the identity:

sin(k − p) = sin(k) cos(p) − cos(k) sin(p)

For each pixel, the constructor caches the sum of the two weighted spatial sines and the sum of the two weighted spatial cosines. During painting, it only needs the sine and cosine of the time phase:

double c = Math.cos(phase), s = Math.sin(phase);
double wave = sine[i] * c - cosine[i] * s;

The same values of c and s apply to all 57,600 pixels. With five turns of phase per eight-second interval, each oscillation takes 1.6 seconds.

Convert displacement to color

The sign selects cyan or pink. The magnitude controls how bright that color becomes:

double glow = Math.min(1, Math.abs(wave) / 1.5);
glow *= glow;

Squaring the normalized magnitude makes weaker values darker and emphasizes stronger peaks and troughs. A dark pixel shows low displacement at that instant; the dark lanes that persist as the ripples move reveal where the waves repeatedly oppose each other.

The renderer writes each color into an integer-backed BufferedImage and then scales the finished image with bilinear interpolation. Working at 180 × 320 keeps the per-frame calculations small while the window can display the image at a larger size.

Animate the result with Swing

A Swing timer requests a repaint approximately every 33 milliseconds. The animation reads time with System.nanoTime() instead of counting repaint events, so a late frame does not slow the intended wave motion. The window and timer run on Swing’s event-dispatch thread.

The renderer is also available through drawFrame(), which accepts a time in seconds. That makes it possible to render the same pattern into an image at a chosen instant without opening the Swing window.

Try changing the pattern

Move the sources closer together and compare the spacing of the dark bands. Then change the wavelength from 21 to 28 in both phase calculations. Keeping everything else fixed lets you see how the spacing changes with wavelength.

The complete Java source is free to copy and run. Explore more examples in the SwingLoops repository.

You can create interactive fireworks in Java Swing by combining Graphics2D, mouse events, and a javax.swing.Timer. Rockets travel toward the position you click, then explode into colorful particles affected by gravity, damping, and fading.

The effect does not require an external graphics library, physics engine, or image assets.

In this SwingLoops example, fireworks launch into a dark night sky above a simple city skyline. Each explosion produces dozens of glowing particles with different colors and movement patterns. You can click several positions to create multiple explosions, and the program launches fireworks automatically when you leave it running.

Source code

Save the following code as InteractiveFireworks.java:

import javax.swing.*;
import java.awt.*;
import java.awt.event.*;
import java.awt.geom.*;
import java.util.*;

public class InteractiveFireworks extends JPanel {
    private static final int W = 540, H = 960;
    private final Random random = new Random();
    private final java.util.List<Rocket> rockets = new ArrayList<>();
    private final java.util.List<Particle> particles = new ArrayList<>();
    private final Timer timer = new Timer(16, e -> update());
    private long lastLaunch;

    public InteractiveFireworks() {
        setPreferredSize(new Dimension(W, H));
        setBackground(new Color(3, 5, 20));

        addMouseListener(new MouseAdapter() {
            @Override
            public void mousePressed(MouseEvent e) {
                double x = e.getX() * W / (double) getWidth();
                double y = e.getY() * H / (double) getHeight();
                launch(x, y);
            }
        });
    }

    @Override
    public void addNotify() {
        super.addNotify();
        lastLaunch = System.currentTimeMillis();
        timer.start();
    }

    @Override
    public void removeNotify() {
        timer.stop();
        super.removeNotify();
    }

    private void launch(double tx, double ty) {
        double x = 40 + random.nextDouble() * (W - 80);
        double y = H;
        double dx = tx - x;
        double dy = ty - y;
        double distance = Math.max(1, Math.hypot(dx, dy));
        double speed = 9 + random.nextDouble() * 3;

        rockets.add(new Rocket(x, y,
                dx / distance * speed,
                dy / distance * speed,
                tx, ty, random.nextFloat()));
    }

    private void update() {
        long now = System.currentTimeMillis();

        if (now - lastLaunch >= 1700) {
            launch(80 + random.nextDouble() * (W - 160),
                    100 + random.nextDouble() * 350);
            lastLaunch = now;
        }

        for (Iterator<Rocket> it = rockets.iterator(); it.hasNext();) {
            Rocket r = it.next();
            double remaining = Point2D.distance(
                    r.x, r.y, r.tx, r.ty);

            if (remaining <= Math.hypot(r.vx, r.vy)) {
                r.x = r.tx;
                r.y = r.ty;
                explode(r);
                it.remove();
            } else {
                r.x += r.vx;
                r.y += r.vy;
            }
        }

        for (Iterator<Particle> it = particles.iterator();
             it.hasNext();) {
            Particle p = it.next();

            p.px = p.x;
            p.py = p.y;
            p.x += p.vx;
            p.y += p.vy;
            p.vx *= .988;
            p.vy = p.vy * .988 + .075;
            p.life -= .013f;

            if (p.life <= 0) it.remove();
        }

        repaint();
    }

    private void explode(Rocket r) {
        int count = 80 + random.nextInt(30);
        int pattern = random.nextInt(3);

        for (int i = 0; i < count; i++) {
            double angle = pattern == 2
                    ? random.nextDouble() * Math.PI * 2
                    : i * Math.PI * 2 / count;

            double speed = 2 + random.nextDouble() * 4;

            if (pattern == 1) {
                speed *= .5 + Math.abs(Math.sin(angle * 2));
            }

            particles.add(new Particle(r.x, r.y,
                    Math.cos(angle) * speed,
                    Math.sin(angle) * speed,
                    r.hue + random.nextFloat() * .08f));
        }
    }

    @Override
    protected void paintComponent(Graphics graphics) {
        super.paintComponent(graphics);
        Graphics2D g = (Graphics2D) graphics.create();
        g.setRenderingHint(RenderingHints.KEY_ANTIALIASING,
                RenderingHints.VALUE_ANTIALIAS_ON);
        g.scale(getWidth() / (double) W,
                getHeight() / (double) H);

        g.setPaint(new GradientPaint(0, 0,
                new Color(3, 5, 20),
                0, H, new Color(20, 9, 44)));
        g.fillRect(0, 0, W, H);

        drawCity(g);

        for (Rocket r : rockets) {
            g.setColor(Color.WHITE);
            g.fill(new Ellipse2D.Double(r.x - 3, r.y - 3, 6, 6));
            g.setColor(new Color(255, 190, 100, 100));
            g.setStroke(new BasicStroke(3));
            g.draw(new Line2D.Double(
                    r.x, r.y + 18, r.x, r.y));
        }

        for (Particle p : particles) {
            Color c = Color.getHSBColor(p.hue % 1f, .8f, 1f);
            int alpha = (int) (p.life * 230);

            g.setColor(new Color(c.getRed(),
                    c.getGreen(), c.getBlue(), alpha / 4));
            g.fill(new Ellipse2D.Double(
                    p.x - 8, p.y - 8, 16, 16));

            g.setColor(new Color(c.getRed(),
                    c.getGreen(), c.getBlue(), alpha));
            g.setStroke(new BasicStroke(2,
                    BasicStroke.CAP_ROUND,
                    BasicStroke.JOIN_ROUND));
            g.draw(new Line2D.Double(p.px, p.py, p.x, p.y));
            g.fill(new Ellipse2D.Double(
                    p.x - 2, p.y - 2, 4, 4));
        }

        g.dispose();
    }

    private void drawCity(Graphics2D g) {
        for (int i = 0; i < 18; i++) {
            int x = i * 32;
            int height = 45 + (i * 37) % 110;

            g.setColor(new Color(8, 12, 28));
            g.fillRect(x, H - height, 35, height);

            g.setColor(new Color(255, 205, 90, 100));
            for (int y = H - height + 12; y < H - 8; y += 18) {
                g.fillRect(x + 8, y, 4, 6);
                g.fillRect(x + 22, y, 4, 6);
            }
        }
    }

    private static class Rocket {
        double x, y, vx, vy, tx, ty;
        float hue;

        Rocket(double x, double y, double vx, double vy,
               double tx, double ty, float hue) {
            this.x = x;
            this.y = y;
            this.vx = vx;
            this.vy = vy;
            this.tx = tx;
            this.ty = ty;
            this.hue = hue;
        }
    }

    private static class Particle {
        double x, y, px, py, vx, vy;
        float hue, life = 1f;

        Particle(double x, double y,
                 double vx, double vy, float hue) {
            this.x = this.px = x;
            this.y = this.py = y;
            this.vx = vx;
            this.vy = vy;
            this.hue = hue;
        }
    }

    public static void main(String[] args) {
        SwingUtilities.invokeLater(() -> {
            JFrame frame = new JFrame("SwingLoops - Fireworks");
            frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
            frame.setContentPane(new InteractiveFireworks());
            frame.pack();
            frame.setLocationRelativeTo(null);
            frame.setVisible(true);
        });
    }
}

Run the example

You need Java 17 or later and a desktop environment capable of running Swing applications.

Open a terminal in the directory containing InteractiveFireworks.java, then compile and run it:

javac InteractiveFireworks.java
java InteractiveFireworks

A window with a preferred drawing area of 540 × 960 pixels opens. Fireworks launch automatically every 1.7 seconds.

Click anywhere in the window to launch a rocket toward that position. Clicking several locations creates multiple simultaneous explosions.

You can change the preferred panel size if the window is too large for your screen.

How does the animation work?

Updating the animation with a Swing Timer

The application uses a javax.swing.Timer to update the animation approximately every 16 milliseconds:

private final Timer timer = new Timer(16, e -> update());

Each update moves the rockets, updates the particles, removes expired objects, and requests a repaint.

The timer starts in addNotify() and stops in removeNotify(), preventing the animation from continuing after the panel is removed.

Because the timer executes its callback on Swing’s Event Dispatch Thread, mouse events, animation updates, and painting share the same thread.

Moving rockets toward the target

Each rocket starts near the bottom of the screen and receives a velocity pointing toward its target.

The direction is calculated from the difference between the target and starting positions:

double dx = tx - x;
double dy = ty - y;
double distance = Math.max(1, Math.hypot(dx, dy));

Math.hypot() calculates the Euclidean distance between two points.

We divide the direction components by this distance and multiply them by the desired speed:

double vx = dx / distance * speed;
double vy = dy / distance * speed;

This ensures that the rocket moves at a consistent speed regardless of its destination.

During each animation update, its position changes according to its velocity:

r.x += r.vx;
r.y += r.vy;

Once the rocket is close enough to reach its target during the next movement, the program triggers an explosion.

Creating particles with circular motion

An explosion produces between 80 and 109 particles.

For a circular burst, each particle receives a different angle:

double angle = i * Math.PI * 2 / count;

The horizontal and vertical velocity components are calculated using:

double vx = Math.cos(angle) * speed;
double vy = Math.sin(angle) * speed;

Together, these calculations distribute particles around the explosion center.

The example also introduces variations in particle speed and direction, producing different explosion shapes.

Adding gravity and damping

After an explosion, particles move independently.

Each frame applies damping and gravity:

p.vx *= .988;
p.vy = p.vy * .988 + .075;

Multiplying velocity by .988 gradually slows the particles.

The additional .075 accelerates them downward because Java2D’s Y coordinate increases toward the bottom of the screen.

The result is a curved trajectory: particles spread outward, slow down, and eventually fall.

This is a simple visual physics simulation rather than a fully realistic model, but it works well for a fireworks animation.

Creating fading particles

Each particle begins with a lifetime of 1.0:

float life = 1f;

Its lifetime decreases with every update:

p.life -= .013f;

The remaining lifetime determines the particle’s transparency:

int alpha = (int) (p.life * 230);

As life approaches zero, the particle becomes less visible.

Expired particles are removed using the iterator, which also prevents the particle collection from growing indefinitely.

Creating a glow effect

The glow is produced by drawing each particle twice.

First, a larger circle is drawn with low opacity:

g.setColor(new Color(
        c.getRed(), c.getGreen(), c.getBlue(), alpha / 4));

g.fill(new Ellipse2D.Double(
        p.x - 8, p.y - 8, 16, 16));

A small, brighter particle is then drawn on top.

The application also draws a short line between each particle’s previous and current positions, creating a glowing motion trail.

This approximates a neon effect using ordinary Java2D shapes, without shaders or blur filters.

Generating firework colors

The example uses Color.getHSBColor() to generate colors:

Color c = Color.getHSBColor(p.hue % 1f, .8f, 1f);

Each rocket receives a random hue, and its particles use nearby hue values.

This gives every explosion a recognizable color theme while still allowing subtle variation between individual particles.

Drawing the night sky

The background uses a GradientPaint that transitions from dark navy to deep purple.

A simple city skyline is drawn using rectangles, with smaller yellow rectangles representing illuminated windows.

These elements provide context for the fireworks without requiring image assets.

Customize the animation

Try changing one parameter at a time to see how it affects the result.

Parameter	Effect
16 in the timer	Animation update interval in milliseconds
1700	Time between automatic launches
80 + random.nextInt(30)	Number of particles per explosion
9 + random.nextDouble() * 3	Rocket speed
.988	Particle damping; smaller values slow particles faster
.075	Gravity; larger values make particles fall faster
.013f	Lifetime reduction; larger values make particles disappear sooner
new Color(3, 5, 20)	Background color

For example, increasing the particle count to 150 makes each firework look fuller, but also increases the amount of rendering work.

Reducing gravity creates a floating, almost magical explosion, while increasing gravity makes particles fall more quickly.

Experimenting with these values is an easy way to create your own animation style.

The complete example uses only Java Swing and Java2D. No external libraries, physics engines, or image assets are required.

Happy coding!

You can create a pendulum wave animation in Java Swing by drawing several pendulums and giving each one a slightly different oscillation frequency. Their movements gradually form changing patterns before returning to alignment.

In this SwingLoops example, 15 glowing pendulums complete different numbers of swings within a shared 24-second cycle. The animation uses only Java Swing and Java 2D, without external libraries or image assets.

import javax.swing.*;
import java.awt.*;
import java.awt.geom.Ellipse2D;
import java.awt.geom.Line2D;

public class PendulumWave extends JPanel {
    private static final int COUNT = 15;
    private static final double CYCLE = 24.0;
    private final long start = System.nanoTime();
    private final Timer timer = new Timer(16, _ -> repaint());

    public PendulumWave() {
        setPreferredSize(new Dimension(540, 960));
        setBackground(new Color(7, 10, 24));
    }

    @Override
    public void addNotify() {
        super.addNotify();
        timer.start();
    }

    @Override
    public void removeNotify() {
        timer.stop();
        super.removeNotify();
    }

    @Override
    protected void paintComponent(Graphics graphics) {
        super.paintComponent(graphics);
        Graphics2D g = (Graphics2D) graphics.create();
        try {
            g.setRenderingHint(RenderingHints.KEY_ANTIALIASING,
                    RenderingHints.VALUE_ANTIALIAS_ON);

            double scale = Math.min(
                    getWidth() / 540.0, getHeight() / 960.0);
            g.translate(getWidth() / 2.0, getHeight() / 2.0);
            g.scale(scale, scale);
            g.translate(-270, -480);

            double time = (System.nanoTime() - start) / 1e9;
            double phase = (time % CYCLE) / CYCLE;

            for (int i = 0; i < COUNT; i++) {
                double pivotX = 270;
                double pivotY = 100 + i * 44;
                double length = 180;

                // Each pendulum completes an integer number
                // of swings during the shared 24-second cycle.
                double angle = 0.95 * Math.cos(
                        2 * Math.PI * (12 + i) * phase);
                double x = pivotX + length * Math.sin(angle);
                double y = pivotY + length * Math.cos(angle);

                Color color = Color.getHSBColor(
                        i / (float) COUNT, 0.75f, 1f);

                g.setComposite(AlphaComposite.SrcOver.derive(0.22f));
                g.setColor(color);
                g.setStroke(new BasicStroke(1.5f));
                g.draw(new Line2D.Double(pivotX, pivotY, x, y));

                g.setComposite(AlphaComposite.SrcOver);
                g.setColor(new Color(110, 120, 145));
                g.fill(new Ellipse2D.Double(
                        pivotX - 2, pivotY - 2, 4, 4));

                for (int glow = 4; glow >= 1; glow--) {
                    double radius = 8 + glow * 4;
                    g.setComposite(
                            AlphaComposite.SrcOver.derive(0.045f));
                    g.setColor(color);
                    g.fill(new Ellipse2D.Double(
                            x - radius, y - radius,
                            radius * 2, radius * 2));
                }

                g.setComposite(AlphaComposite.SrcOver);
                g.setColor(color);
                g.fill(new Ellipse2D.Double(x - 8, y - 8, 16, 16));
                g.setColor(new Color(255, 255, 255, 190));
                g.fill(new Ellipse2D.Double(x - 3, y - 4, 4, 4));
            }
        } finally {
            g.dispose();
        }
    }

    static void main() {
        SwingUtilities.invokeLater(() -> {
            JFrame frame = new JFrame("SwingLoops - Pendulum Wave");
            frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
            frame.setContentPane(new PendulumWave());
            frame.pack();
            frame.setLocationRelativeTo(null);
            frame.setVisible(true);
        });
    }
}

Run the example

Install a Java Development Kit and open a terminal in the directory containing the source file:

javac PendulumWave.java
java PendulumWave

A desktop environment is required to display the Swing window. Close the window to stop the application.

The preferred drawing area is 540 × 960 pixels. If the window is too tall for your display, change the dimensions to 405, 720. The drawing scales proportionally when you resize the window.

Calculating the pendulum angle

Each pendulum swings, according to a cosine function:

double angle = 0.95 * Math.cos(2 * Math.PI * (12 + i) * phase);

The formula has three main parts:

• 0.95 is the angular amplitude in radians, approximately 54.4 degrees.
• 2 * Math.PI represents one complete oscillation of the cosine function.
• 12 + i determines how many oscillations the pendulum completes during the shared cycle.

Cosine varies between −1 and 1, so each pendulum’s angle varies between −0.95 and 0.95 radians.

In the beginning, every cosine evaluates to 1. All pendulums therefore start at the same angle.

Why do the pendulums return to alignment?

Elapsed time is converted into a repeating phase:

double phase = (time % CYCLE) / CYCLE;

With CYCLE set to 24 seconds, the phase advances from zero toward one, then returns to zero.

The first pendulum completes 12 oscillations during that interval. Each subsequent pendulum completes one more:

Pendulum	Oscillations in 24 seconds	Period
First	12	2 seconds
Second	13	About 1.85 seconds
Eighth	19	About 1.26 seconds
Fifteenth	26	About 0.92 seconds

Because all oscillation counts are integers, every pendulum completes a whole number of swings at the end of 24 seconds.

For an integer n:

cos(2π × n) = 1

The pendulums return to their starting angles and the pattern repeats. During the cycle, their different frequencies produce the changing wave patterns.

Here, “alignment” means the pendulums have the same angle. Their pivots remain vertically separated.

Converting the angle into screen coordinates

Once the angle is known, the bob’s position is calculated relative to its pivot:

double x = pivotX + length * Math.sin(angle);
double y = pivotY + length * Math.cos(angle);

The angle is measured from the downward vertical direction.

When the angle is zero:

sin(0) = 0
cos(0) = 1

Therefore:

x = pivotX
y = pivotY + length

The bob hangs directly below its pivot.

A positive angle moves the bob to the right, while a negative angle moves it to the left. Swing’s screen coordinates increase downward, which is why the vertical offset is added to pivotY.

Is this a physical pendulum simulation?

This example uses prescribed sinusoidal motion to create a visual effect.

All pendulums have the same drawn length, while their frequencies are assigned independently. Real pendulum wave demonstrations commonly use different lengths to get different periods.

For a simple pendulum at small angles, the approximate period is:

T = 2π × √(L / g)

Here, L is the pendulum length and g is gravitational acceleration. Longer pendulums swing more slowly.

Our animation does not solve that physical model. Its amplitude is also larger than the small-angle range where a real pendulum closely follows sinusoidal angular motion.

Creating the glow

Each bob is surrounded by four overlapping circles:

for (int glow = 4; glow >= 1; glow--) {
    double radius = 8 + glow * 4;
    // Draw a translucent circle.
}

Each circle has low opacity. Their overlapping areas become brighter toward the center, approximating a soft glow without applying a blur filter.

An opaque-colored bob and a small pale highlight are drawn afterward.

The code explicitly restores the composite before drawing opaque elements so that the glow’s transparency does not affect them.

Updating the animation safely

A Swing timer requests a repaint approximately every 16 milliseconds:

private final Timer timer = new Timer(16, _ -> repaint());

This targets roughly 60 updates per second, but actual timing depends on the system and Swing’s event queue.

The animation calculates positions from elapsed time rather than counting frames. A delayed repaint, therefore, does not change the intended 24-second cycle.

The interface is created with SwingUtilities.invokeLater(). Timer callbacks and painting also execute on Swing’s event-dispatch thread.

Customize the animation

Try changing one parameter at a time:

Parameter	Effect
COUNT	Changes the number of pendulums. Larger counts may require tighter vertical spacing.
CYCLE	Changes the shared cycle duration. Larger values slow every pendulum.
12 + i	Changes the oscillation counts. Keep integer counts to preserve the shared loop.
0.95	Changes the maximum swing angle in radians.
length	Changes the drawn string length without changing the assigned frequency.
i * 44	Changes the vertical spacing between pivots.
0.75f in getHSBColor()	Changes color saturation.

For example, replacing 12 + i with 12 + 2 * i increases the frequency difference between neighboring pendulums while retaining integer oscillation counts.

Explore the SwingLoops repository on GitHub for the series’ source code collection.
